RDS 80 Ersa Soldering Station
electronically controlled soldering station, 80 W, non antistatic
The universal, digital soldering station from Ersa
The RDS 80 suits all soldering tasks with medium heat demands in production, repair and R&D or for all ambitious hobbyists. ESD requirements should not be present while using this stations. The RT 80 soldering iron can be used with all tips of the series 832 and series 842.
Highlights RDS 80Ersa Soldering Station
- Digital soldering station with robust and powerful RT 80 soldering iron
- PTC heating technology with 290 W heat-up power
- Large, clearly legible display
- Three programmable fix temperatures
- Stepless temperature setting from 150 to 450 °C
- Standby and auto-power-off function
- Large selection of competitive, exchangable soldering tips (series 832 and series 842)
VideosRDS 80
Ersa explains #1 – Soldering tip care
Ersa explains #1 – Soldering tip care
RDS 80Ersa Soldering Station
Technical Data
Dimensions (W x D x H) in mm:
110 x 147 x 105
Weight in kg:
3,2
Antistatic Design (y/n):
n
Power Rating in W:
80
Nominal voltage in V AC:
230
Secondary voltage in V:
24
Heat up time in sec:
40
Temperature range in °C:
150-450
Digital display (y/n):
y
Test symbol:
CE, VDE
Connectable
Article-No.:
Description
0890CDJ:
RT 80
0810CDJ:
BASIC TOOL 60 (discontinued)
Available Versions
Article-No.:
Description
0RDS80:
RDS 80 mit RT 80
