Kurtz AL18-12FSC Low Pressure Casting Machine

1 shot, 2 engine blocks!
Superior tool change with change times of less than 30 min: "There's no such thing as can´t"! - we have written this slogan on our flag. We regard the wishes and requirements of our customers as a challenge. Thus, together with the customer, we have created highly flexible and economical solutions with which the most complex castings made of aluminum alloys can be produced extremely economically on the basis of the low-pressure die casting process.
Highlights AL18-12FSCKurtz Low Pressure Casting
-
Swiveling core pulls
-
Innovative coupling technology for the fastest mold changes and shortest maintenance times
-
Extremely low maintenance costs
-
Low pressure control with proportional technology
-
Interchangeable furnace system
Applications AL18-12FSCKurtz Low Pressure Casting
Technical Data Type SOKurtz Low Pressure Casting
17-11/AZ79
Mould mounting area in mm (between the columns):
1,780 x 1,140
Light width max. (in mm):
2,000
Stroke closing plate (in mm):
1,400
Other sizes available on request
21-13/AZ80
Mould mounting area in mm (between the columns):
2,100 x 1,340
Light width max. (in mm):
2,000
Stroke closing plate (in mm):
1,400
Other sizes available on request
18-16
Mould mounting area in mm (between the columns):
1,800 x 1,680
Light width max. (in mm):
2,600
Stroke closing plate (in mm):
1,800
Other sizes available on request
