Smart technology for your electronics manufacturing

With the SMARFLOW, Ersa has added a compact selective soldering system to its technologically leading selective soldering series. The SMARTFLOW has a smaller footprint than its big sisters from the VERSAFLOW family. This batch system impresses with its state-of-the-art technology and simple operation. The SMARTFLOW easily solders PCBs measuring 508 x 508 mm (20 x 20") and requires no more space than a modern manual soldering workstation. This makes it ideal as a starter system or for smaller production runs. In line with the motto “compact without compromise”, the customer does not have to compromise on anything with this system.

HighlightsSMARTFLOW 2020

  • "Plug and Solder" – the compact start up model
  • Perfect for manufacturing islands
  • Large PCB formats
  • Extremely maintenance-friendly
  • Wear-free induction pump
  • Full-area heating
  • Modern process visualization with ERSASOFT

SMARTFLOW 2020Ersa Videos

Ersa Selektivlöten – SMARTFLOW 2020

Ersa Selektivlöten – SMARTFLOW 2020

SMARTFLOW 2020Ersa Selective Soldering

Technical data



    Length:
    1,750 mm
    Width:
    1,450 mm
    Height:
    1,520 mm

    Conveyor system

    • Universal mask holder
    • PCB width: 15-508 mm
    • PCB length: 15-508 mm)
    • Max. Top PCB structures up to 80 mm
    • Max. PCB superstructures at the bottom up to 60 mm
    • Max. PCB weight: 3 kg

    Fluxer/Preheating/Solder module

    • Fluxer: Drop jet in various sizes

    • Preheating: IR radiation heating at the bottom or combination of IR at the bottom and IR at the top

    • Soldering module:
          electromagnetic solder pot
          Mini wave/mini dip (optional)
